These modular pressure controllers combine cutting-edge control/measurement technology, modular design, and user-friendly features. The FAK-663 controller series is optimized for low pressure work by utilizing FAK’s proven low-pressure pump technology in combination with control capabilities that revolutionized the industry as seen in the well-known handheld model ADT760. For users who require automated production, test, and calibration, Additel has the workload covered with these pressure controllers. The FAK-663 can be quickly outfitted with two controlling modules and one reference barometric module to cover a wide pressure range.

Features：

1.   Pressure ranges from -380 inH2O (-0.95 bar) to 2500 inH2O (7 bar)

2.   Two removable internal pressure modules with multi-range selection

3.   0.02%FS accuracy

4.   Control stability of 0.003%FS

5.   Ultra-High speed pressure generation and control

6.   Optional barometric pressure module

7.   Built-in differential pressure pump

8.   Large 7" color touch screen display

9.   Modular design for easy maintenance, greatly reducing on-site downtime

10.   Emulation mode

MODELS：

The FAK-663-LLP is designed for low pressure calibration from -380 to 400 inH₂O (-13.5 to 14.5 psi | -0.95 to 1 bar). This unit has selectable modules available in 0.01%FS or 0.02%FS accuracy, or 0.05%FS for DP2 and DP5 modules and 0.02%FS for DP10 modules. All measurements can be made in differential or gauge pressures.

The FAK-663-D is designed for low pressure calibration from -380 to 2500 inH₂O (-13.5 to 100 psi | -0.95 to 7 bar). This unit has selectable modules available in 0.01%FS or 0.02%FS accuracy. All measurements can be made in differential or gauge pressures.
